UNITRONIC® RE-2Y(ST)Yv

Bodite prvi in ocenite ta izdelek

Naziv

Koda izdelka

test voltage conductor/conductor

Testna napetost vodnika/opleta

Nominal cross section conductor (mm2)

Cena

Količina

UNITRONIC® RE-2Y(ST)YV 4X2X0,5 BK

0032413

2 kV

1 kV

0.5 mm2

2,46 €

Dolžina *
Poljubna dolžina * Naročilu bo dodan strošek manipulacije in reza 15€ na rez

Na zalogi, predviden rok dobave 5-8 delovnih dni.

UNITRONIC® RE-2Y(ST)YV 4X2X1,3 BK

0032432

2 kV

1 kV

1.3 mm2

3,87 €

Dolžina *
Poljubna dolžina * Naročilu bo dodan strošek manipulacije in reza 15€ na rez

Na zalogi, predviden rok dobave 5-8 delovnih dni.

UNITRONIC® RE-2Y(ST)YV 8X2X1,3 BK

0032433

2 kV

1 kV

1.3 mm2

7,02 €

Dolžina *
Poljubna dolžina * Naročilu bo dodan strošek manipulacije in reza 15€ na rez

Na zalogi, predviden rok dobave 5-8 delovnih dni.

UNITRONIC® RE-2Y(ST)YV S 2X2X1,3 BU

1032423

2 kV

1 kV

1.3 mm2

2,40 €

Dolžina *

Na zalogi, predviden rok dobave 5-8 delovnih dni.

UNITRONIC® RE-2Y(ST)YV S 2X2X0,5 BU

1032401

2 kV

1 kV

0.5 mm2

1,57 €

Dolžina *

Na zalogi, predviden rok dobave 5-8 delovnih dni.

UNITRONIC® RE-2Y(ST)YV S 2X2X0,5 BK

1032412

2 kV

1 kV

0.5 mm2

1,51 €

Dolžina *

Na zalogi, predviden rok dobave 5-8 delovnih dni.

UNITRONIC® RE-2Y(ST)YV S 2X2X1,3 BK

1032431

2 kV

1 kV

1.3 mm2

2,39 €

Dolžina *

Min. količina za naročanje: 1000

Na zalogi, predviden rok dobave 5-8 delovnih dni.

Benefits

Aluminium-laminated plastic foil static screen with tin-plated drain wire minimises the interference of high frequency, electromagnetic fields
Decoupling of circuits by means of twisted-pair (TP) design (crosstalk effects)
Low capacitance due to polyolefin-based insulation

Applications

Electrically intended for use when modern process computers have to process large volumes of data, e.g. high-capacity computer systems in waste incineration plants or sewage treatment plants
These cables are suitable for fixed installation in dry or damp rooms and, in case of versions with a black outer sheath, also for outdoor use
In measurement and control engineering
Thanks to reinforced, nominal/ minimum average wall thickness of the outer sheath of at least 1.8 mm, for applications, where a reinforced outer sheath may turn out to be advantageous.

Documentation

Notes

Please find our standard lengths at: www.lappkabel.de/kabel-standardlaengen.
If applicable, the prices are solid metal prices without surcharges and VAT. Sales only to business customers.
Unless specified otherwise, the product values shown are rated values at room temperature. You can receive further values, such as tolerances, upon request if they are available and have been released for publication.
Photographs and graphics are not to scale and do not represent detailed images of the respective products.
