UNITRONIC® BUS PB FD P HYBRID

Naziv
Koda izdelka
Maks. najvišja delovna napetost (ne za napajalne aplikacije)
test voltage conductor/conductor
Testna napetost vodnika/opleta
Cena
Količina
+
UNITR. BUS PB FD P HYBRID 1X2X0,64+4X1,5
2170495
100 V
0.6 kV
0.6 kV
5,55 €
*
*

Naročilu bo dodan strošek manipulacije in reza 15€ na rez

Na zalogi, predviden rok dobave 5-8 delovnih dni.

Benefits

  • Cables can be used for PROFIBUS-DP as well as PROFIBUS-FMS and FIP
  • For use where the combination of a halogen-free outer sheath with properties similar to PUR and enhanced flame-retardance is required
  • For highly flexible applications (power chains, moving machine parts)

Applications

  • PROFIBUS DP (in accordance with DIN 19245 and EN 50170, e.g. for SIEMENS SIMATIC® NET, also suitable for FIP - Factory Instrumentation Protocol).

Notes

  • LAPP Kabel is a member of the PROFIBUS user organisation (PNO).
  • Please find our standard lengths at: www.lappkabel.de/kabel-standardlaengen.
  • If applicable, the prices are solid metal prices without surcharges and VAT. Sales only to business customers.
  • Unless specified otherwise, the product values shown are rated values at room temperature. You can receive further values, such as tolerances, upon request if they are available and have been released for publication.
  • SIMATIC® is a registered trademark of SIEMENS AG. FIP is a registered trademark of World FIP.
  • Photographs and graphics are not to scale and do not represent detailed images of the respective products.
