N2XS(F)2Y

Name: N2XS(F)2Y
Price: 120.61 EUR
Availability: OutOfStock

Naziv

Koda izdelka

Testna napetost

Max. conductor resistance at 20 °C

Nominal cross section conductor (mm2)

Cena

Količina

N2XS(F)2Y 1x630 RM/35 18/30kV

38107827

45 kV

0.0283 ?/km

630 mm2

120,61 €

Na zalogi, predviden rok dobave 5-8 delovnih dni.

Benefits

With additional wrapping to protect against water penetration in the longitudinal direction after mechanical damage.
VDE-certified cable with ?VDE? testing mark for proven reliability and quality according to VDE 0276-620.
Robust during installation and operation thanks to durable PE outer sheath.
Cross-linked conductive layers above and below the core insulation prevent partial discharges and enable constant operational safety.
Available in voltage classes 6/10 (12) kV, 12/20 (24) kV and 18/30 (36) kV.
Available in conductor cross-sections up to 800 mm2.

Suitable for high mechanical stress due to the PE outer sheath.
Suitable for energy distribution in medium-voltage networks.
Also suitable for installation indoors and in closed installation ducts for energy supplier, industrial and distribution networks, but not flame-retardant according to IEC 60332-1-2.
For fixed installation in water, air and soil. In the ground, the minimum installation depth without additional, suitable underground protection is 0.6 m, and at least 0.8 m under roads (according to HD 620/VDE 0276-620 Part 10-C (point 4)).
Suitable for use in AC and DC charging infrastructures for electromobility.
Suitable for outdoor use.
Suitable for use at temperatures up to -40°C.

Trade product, not a LAPP product.
Please find our standard lengths at: www.lappkabel.de/kabel-standardlaengen.
If applicable, the prices are solid metal prices without surcharges and VAT. Sales only to business customers.
Unless specified otherwise, the product values shown are rated values at room temperature. You can receive further values, such as tolerances, upon request if they are available and have been released for publication.
Photographs and graphics are not to scale and do not represent detailed images of the respective products.
