Mobility Dock Charging station Mode 2 Type 2

Naziv
Koda izdelka
Product type
Charging mode
Nominal voltage
Cena
Količina
+
M2M-EFT10A-xx-1PTN-MT2-swor
5555925000
Mode 2 charger
Mode 2 according to IEC 61851
230 V AC rms according to IEC
319,05 €
Na zalogi, predviden rok dobave 5-8 delovnih dni.
+
M2M-JT8A-xx-1PTN-MT2-swor Lapp CH
5555925005
Mode 2 charger
Mode 2 according to IEC 61851
230 V AC rms according to IEC
328,96 €
Rok dobave sporočimo po obdelavi naročila.
+
M2M-KT6A-xx-1PTN-MT2-swor Lapp DK
5555925006
Mode 2 charger
Mode 2 according to IEC 61851
230 V AC rms according to IEC
328,96 €
Rok dobave sporočimo po obdelavi naročila.

Benefits

  • The charging process starts automatically when requested by the vehicle.
  • Compact and ergonomic design as well as easy handling, without cable clutter, light and space-saving.
  • With rear support to stabilise the appliance against the wall.
  • Enables charging capacities of up to 2.3 kW and is therefore ideal for charging overnight or at work.
  • Can be used flexibly: both on the move and at home. Always and wherever a household socket is within reach.
  • Functions as an adapter between a Type 2 vehicle connector and a household plug (available as plug type E/F, G, J or K depending on the country variant).
  • Maximum safety thanks to a range of integrated monitoring functions (self-test at start, detection of residual current, overcurrent, overvoltage and undervoltage, temperature sensors and much more).

Applications

  • Also suitable for charging electric motorbikes.
  • For mobile charging of electric and plug-in hybrid cars with a Mode 3 charging cable and Type 2 plugs at household sockets (AC power supply).
  • Suitable for outdoor use, subject to the type of socket and the temperature range.

Notes

  • Photographs and graphics are not to scale and do not represent detailed images of the respective products.
  • If applicable, the prices are solid metal prices without surcharges and VAT. Sales only to business customers.
  • Unless specified otherwise, the product values shown are rated values at room temperature. You can receive further values, such as tolerances, upon request if they are available and have been released for publication.
