Slika EPIC® H-K 6/12
Slika EPIC® H-K 6/12 Slika EPIC® H-K 6/12 Slika EPIC® H-K 6/12 Slika EPIC® H-K 6/12 Slika EPIC® H-K 6/12 Slika EPIC® H-K 6/12 Slika EPIC® H-K 6/12 Slika EPIC® H-K 6/12 Slika EPIC® H-K 6/12 Slika EPIC® H-K 6/12 Slika EPIC® H-K 6/12 Slika EPIC® H-K 6/12

EPIC® H-K 6/12

Bodite prvi in ​​ocenite ta izdelek
Naziv
Koda izdelka
Min. presek povezovalnega vodnika za napetostne kontakte (mm2)
Maks. presek povezovalnega vodnika za napajalne kontakte (mm2)
Min. presek povezovalnega vodnika za signalne kontakte (mm2)
Cena
Količina
+
EPIC® H-K 006.1/12 MAS 2.5-8
381167285
2.5 mm2
8 mm2
0.2 mm2
40,86 €
Rok dobave sporočimo po obdelavi naročila.
+
EPIC® H-K 006.2/12 MAS 6-10
381167286
6 mm2
10 mm2
0.2 mm2
34,03 €
Rok dobave sporočimo po obdelavi naročila.
+
EPIC® H-K 006.1/12 FAS 2.5-8
381167287
2.5 mm2
8 mm2
0.2 mm2
40,86 €
Rok dobave sporočimo po obdelavi naročila.
+
EPIC® H-K 006.2/12 FAS 6-10
381167288
6 mm2
10 mm2
0.2 mm2
34,03 €
Rok dobave sporočimo po obdelavi naročila.

Benefits

  • Signal contacts: Easy to service screw connection enables assembly without special tools.
  • Easy to assemble due to straight conductor insertion.
  • Power contacts: Axial screw termination technology allows service-friendly connection without a special crimping tool, saves costs and is suitable for detachable connections.
  • Made of robust plastic (flammability class V-0 according to the UL94 testing procedure for the flammability of plastics).
  • Combination insert for high power supply and simultaneous signal transmission.

Applications

  • For use with the rectangular connector housings of the EPIC® H-B series.
  • For connecting devices and machines to a power supply in various applications, including signal transmission.

Documentation

Notes

  • If applicable, the prices are solid metal prices without surcharges and VAT. Sales only to business customers.
  • Photographs and graphics are not to scale and do not represent detailed images of the respective products.
  • Unless specified otherwise, the product values shown are rated values at room temperature. You can receive further values, such as tolerances, upon request if they are available and have been released for publication.
