Naziv
Koda izdelka
Maks. upor kontakta (mOhms)
Min. presek povezovalnega vodnika za napetostne kontakte (mm2)
Maks. presek povezovalnega vodnika za napajalne kontakte (mm2)
Cena
Količina
+
EPIC® H-K 004.2/4 MAS 14-22
381167280
1 m?
14 mm2
22 mm2
40,09 €
Rok dobave sporočimo po obdelavi naročila.
+
EPIC® H-K 004.1/4 FAS 6-16
381167281
1 m?
6 mm2
16 mm2
48,07 €
Rok dobave sporočimo po obdelavi naročila.
+
EPIC® H-K 004.2/4 FAS 14-22
381167282
1 m?
14 mm2
22 mm2
40,09 €
Rok dobave sporočimo po obdelavi naročila.
+
EPIC® H-K 004.1/4 MAS 6-16
381167279
1 m?
6 mm2
16 mm2
48,07 €
Rok dobave sporočimo po obdelavi naročila.

Benefits

  • Power contacts: Axial screw termination technology allows service-friendly connection without a special crimping tool, saves costs and is suitable for detachable connections.
  • Made of robust plastic (flammability class V-0 according to the UL94 testing procedure for the flammability of plastics).
  • The small design size make it suitable for use in limited spaces.
  • Signal contacts: A cage spring connection enables assembly without special tools and establishes a vibration-proof connection between the contact and the cable. Strands can be connected with or without an end sleeve.
  • Combination insert for high power supply and simultaneous signal transmission.
  • Easy to assemble due to straight conductor insertion.

Applications

  • For use with the rectangular connector housings of the EPIC® H-B series.
  • For connecting devices and machines to a power supply in various applications, including signal transmission.

Notes

  • Photographs and graphics are not to scale and do not represent detailed images of the respective products.
  • If applicable, the prices are solid metal prices without surcharges and VAT. Sales only to business customers.
  • Unless specified otherwise, the product values shown are rated values at room temperature. You can receive further values, such as tolerances, upon request if they are available and have been released for publication.
