EPIC® DATA CAN M12T

Naziv

Koda izdelka

Min. delovna temperatura

Maks. delovna temperatura

Veljaven Fieldbus ali Ethernet Sistem

Cena

Količina

AB-C5-M12T-2XM12FS DN

22260765

-25 °C

90 °C

Sensor/Actuator

11,61 €

Min. količina za naročanje: 5

Informativni dobavni rok: 5-8 delovnih dni. Predviden dobavni rok za izbrano količino prosimo preverite v košarici.

Benefits

Cost-effective, efficient wiring of fieldbus and sensor/ actuator installations
Space-saving due to compact dimensions
Robust design
Robust, flame-retardant TPU housing with integrated vibration protection for applications with shock and vibration.
Realizes two M12 outlets (plug and socket) in close proximity to each other to save space.
When plugged in, protection class IP 65 and IP 67 can be achieved.
Enables parallel branching of sensor/actuator signals directly in the field and thus reduces the wiring effort, as enlargers can be installed without terminals or control cabinet work.

For universal data and signal transmission in the area of sensors and actuators at field level.
For fieldbus communication in CAN- and CANopen-based networks.
For connecting patch cables with 5-pin, A-coded M12 connectors.

DeviceNet is a registered trademark of the user organisation ODVA.
If applicable, the prices are solid metal prices without surcharges and VAT. Sales only to business customers.
Photographs and graphics are not to scale and do not represent detailed images of the respective products.
Unless specified otherwise, the product values shown are rated values at room temperature. You can receive further values, such as tolerances, upon request if they are available and have been released for publication.
