ÖLFLEX® SERVO FD zeroCM

Naziv
Koda izdelka
test voltage conductor/conductor
Testna napetost vodnika/opleta
test voltage power cores
Cena
Količina
+
ÖLFLEX® SERVO FD zeroCM 3X2,5+1G1,5
1023471
4 kV
4 kV
4 kV
11,65 €
*
Na zalogi, predviden rok dobave 5-8 delovnih dni.
+
ÖLFLEX® SERVO FD zeroCM 3X4+1G2,5
1023472
4 kV
4 kV
4 kV
14,30 €
*
Na zalogi, predviden rok dobave 5-8 delovnih dni.
+
ÖLFLEX® SERVO FD zeroCM 3X6+1G4
1023473
4 kV
4 kV
4 kV
18,34 €
*
Na zalogi, predviden rok dobave 5-8 delovnih dni.
+
ÖLFLEX® SERVO FD zeroCM 3X10+1G6
1023474
4 kV
4 kV
4 kV
24,91 €
*
Na zalogi, predviden rok dobave 5-8 delovnih dni.
+
ÖLFLEX® SERVO FD zeroCM 3X16+1G10
1023475
4 kV
4 kV
4 kV
35,12 €
*
Na zalogi, predviden rok dobave 5-8 delovnih dni.
+
ÖLFLEX® SERVO FD zeroCM 3X1,5+1G1
1023470
4 kV
4 kV
4 kV
9,75 €
*
Na zalogi, predviden rok dobave 5-8 delovnih dni.

Benefits

  • Particularly resistant to oil and drilling fluids and therefore ideal for harsh environments.
  • Reduces EMC interference at the frequency converter and thus enables almost double installation lengths.
  • Future-proof for future drive generations with higher cycle frequencies.
  • Faster and error-free connection with just one instead of three protective conductors.
  • The zeroCM® technology with a completely electrical symmetrical cable design has proven to reduce leakage currents by up to 60% compared to conventional motor cables.
  • Halogen-free and flame-retardant materials reduce the possible hazards in the event of a fire.
  • UL/CSA certification according to technical data enables the product to be used in the North American market.
  • Durable cable chain use with medium travel distances or increased acceleration (LAPP performance class “Core Line”).
  • Extremely weather-resistant with a wide temperature range.

Applications

  • Especially for environments where electromagnetic compatibility (EMC) is required.
  • Cable design enables highly flexible, constantly flexing use in moving machine parts and cable chains.
  • Can be used in dry, damp and, especially, harsh and oily environments.
  • For connecting frequency converters and motors.
  • Suitable for outdoor use.
  • The PU outer sheath is resistant to mineral oil-based lubricants and is highly chemical resistant.
  • Flexible use up to -40°C.
  • The PU outer sheath withstands high mechanical loads.

Notes

  • If applicable, the prices are solid metal prices without surcharges and VAT. Sales only to business customers.
  • Photographs and graphics are not to scale and do not represent detailed images of the respective products.
  • Unless specified otherwise, the product values shown are rated values at room temperature. You can receive further values, such as tolerances, upon request if they are available and have been released for publication.
