ÖLFLEX® SERVO FD 7OCS

Naziv
Koda izdelka
test voltage conductor/conductor
Testna napetost vodnika/opleta
test voltage power cores
Cena
Količina
+
ÖLFLEX® SERVO FD 7OCS 4G1,5+(2x1,5)+(4x0
1023380
4 kV
2 kV
4 kV
9,49 €
*
*

Naročilu bo dodan strošek manipulacije in reza 15€ na rez

Na zalogi, predviden rok dobave 5-8 delovnih dni.
+
ÖLFLEX® SERVO FD 7OCS 4G2,5+(2x1,5)+(4x0
1023381
4 kV
2 kV
4 kV
11,17 €
*
*

Naročilu bo dodan strošek manipulacije in reza 15€ na rez

Na zalogi, predviden rok dobave 5-8 delovnih dni.
+
ÖLFLEX® SERVO FD 7OCS 4G1,5+(1xZ50)+2x(2x
1023387
4 kV
2 kV
4 kV
11,11 €
*
Rok dobave sporočimo po obdelavi naročila.
+
ÖLFLEX® SERVO FD 7OCS 4G4+(1xZ50)+2x(2x1)
1023389
4 kV
2 kV
4 kV
15,57 €
*
Rok dobave sporočimo po obdelavi naročila.
+
ÖLFLEX® SERVO FD 7OCS 4G2,5+(2x1)+(2x0,30
1023374
4 kV
2 kV
4 kV
11,41 €
*
Na zalogi, predviden rok dobave 5-8 delovnih dni.
+
ÖLFLEX® SERVO FD 7OCS 4G22AWG+(2x22AWG)+
1023385
2 kV
1 kV
2 kV
6,52 €
*
*

Naročilu bo dodan strošek manipulacije in reza 15€ na rez

Na zalogi, predviden rok dobave 5-8 delovnih dni.
+
ÖLFLEX® SERVO FD 7OCS 4G19AWG+(2x21AWG)+
1023386
2 kV
1 kV
2 kV
7,40 €
*
*

Naročilu bo dodan strošek manipulacije in reza 15€ na rez

Na zalogi, predviden rok dobave 5-8 delovnih dni.
+
ÖLFLEX® SERVO FD 7OCS 4G2,5+(1xZ50)+2x(2x
1023388
4 kV
2 kV
4 kV
13,72 €
*
Rok dobave sporočimo po obdelavi naročila.
+
ÖLFLEX® SERVO FD 7OCS 4G4+(2x1)+(2x0,30+2
1023376
4 kV
2 kV
4 kV
14,72 €
*
Na zalogi, predviden rok dobave 5-8 delovnih dni.
+
ÖLFLEX® SERVO FD 7OCS 4G1,5+(2x0,75)+(2x0
1023373
4 kV
2 kV
4 kV
9,63 €
*
Na zalogi, predviden rok dobave 5-8 delovnih dni.
+
ÖLFLEX® SERVO FD 7OCS (4G19AWG+(2x21AWG)+
1023379
2 kV
1 kV
2 kV
6,41 €
*
*

Naročilu bo dodan strošek manipulacije in reza 15€ na rez

Na zalogi, predviden rok dobave 5-8 delovnih dni.
+
ÖLFLEX® SERVO FD 7OCS (4G22AWG+(2x22AWG)+
1023378
2 kV
1 kV
2 kV
5,65 €
*
*

Naročilu bo dodan strošek manipulacije in reza 15€ na rez

Na zalogi, predviden rok dobave 5-8 delovnih dni.
+
(4G4+(2x1)+(2x24AWG+2x2x26AWG))
1023372
4 kV kV
2 kV kV
4 kV kV
16,77 €
*
*

Naročilu bo dodan strošek manipulacije in reza 15€ na rez

Rok dobave sporočimo po obdelavi naročila.
+
ÖLFLEX® SERVO FD 7OCS (4G2,5+(2x1)+(2x24
1023371
4 kV
2 kV
4 kV
10,06 €
*
*

Naročilu bo dodan strošek manipulacije in reza 15€ na rez

Rok dobave sporočimo po obdelavi naročila.
+
(4G4+(1x20AWG)+(3x1))
1023384
4 kV kV
2 kV kV
4 kV kV
17,56 €
*
*

Naročilu bo dodan strošek manipulacije in reza 15€ na rez

Rok dobave sporočimo po obdelavi naročila.
+
ÖLFLEX® SERVO FD 7OCS (4G1,5+(2x0,75)+(4x
1023375
4 kV
2 kV
4 kV
9,46 €
*
*

Naročilu bo dodan strošek manipulacije in reza 15€ na rez

Na zalogi, predviden rok dobave 5-8 delovnih dni.
+
(4G1,5+(1x20AWG)+(3x1))
1023382
4 kV kV
2 kV kV
4 kV kV
10,17 €
*
*

Naročilu bo dodan strošek manipulacije in reza 15€ na rez

Rok dobave sporočimo po obdelavi naročila.
+
ÖLFLEX® SERVO FD 7OCS (4G1,5+(2x0,75)+(2x
1023370
4 kV kV
2 kV kV
4 kV kV
8,33 €
*
*

Naročilu bo dodan strošek manipulacije in reza 15€ na rez

Rok dobave sporočimo po obdelavi naročila.
+
(4G2,5+(1x20AWG)+(3x1))
1023383
4 kV kV
2 kV kV
4 kV kV
12,22 €
*
*

Naročilu bo dodan strošek manipulacije in reza 15€ na rez

Rok dobave sporočimo po obdelavi naročila.

Benefits

  • Durable cable chain use with long travel distances or high acceleration (LAPP performance class “Extended Line”). This saves costs and increases the efficiency of machines.
  • Compatible with single-cable technology interfaces from many manufacturers.
  • Allows space-saving installation without additional encoder cable. Instead of the encoder cable, integrated signal pairs, signal cores or star quad bundles take over the signal transmission.
  • Space-saving and weight-saving hybrid cable for simultaneous power supply, signal and data transmission (single-cable technology).
  • Ideal protection against electromagnetic interference thanks to copper screening braiding with a high degree of coverage.
  • Highly flexible cable design means maximum product performance.
  • Low-capacitance core insulation for long transmission paths.
  • UL/CSA certification according to technical data enables the product to be used in the North American market.
  • Reduced connection costs due to less cabling work and quick installation of fewer components.
  • Available in various cable design variants according to the required interface compatibility.

Applications

  • For connecting frequency converters and servo motors.
  • Especially for environments where electromagnetic compatibility (EMC) is required.
  • Can be used in dry, wet and especially in harsh and oily environments.
  • The PU outer sheath withstands high mechanical loads.
  • The PU outer sheath is resistant to mineral oil-based lubricants and is highly chemical resistant.
  • Suitable for outdoor use.
  • Flexible use up to -40°C.
  • The cable design allows highly flexible, continuously flexing use in moving machine parts and in the cable chain, with horizontal travel distances of up to 20 m.

Notes

  • Please find our standard lengths at: www.lappkabel.de/kabel-standardlaengen.
  • If applicable, the prices are solid metal prices without surcharges and VAT. Sales only to business customers.
  • Unless specified otherwise, the product values shown are rated values at room temperature. You can receive further values, such as tolerances, upon request if they are available and have been released for publication.
  • DESINA - Decentralised and standardised installation technology for machine tools and production systems.
  • Photographs and graphics are not to scale and do not represent detailed images of the respective products.
