ÖLFLEX® ROBOT 928

Bodite prvi in ocenite ta izdelek

Naziv

Koda izdelka

test voltage conductor/conductor

Max. conductor resistance at 20 °C

Nominal cross section conductor (mm2)

Cena

Količina

ÖLFLEX® ROBOT 928 12x0,34

10282541

1.5 kV

57.7 ?/km

0.34 mm2

2,80 €

Ni zaloge, predviden rok dobave: 5. 07. 2026.

ÖLFLEX® ROBOT 928 2x0,34

10282538

1.5 kV

57.7 ?/km

0.34 mm2

0,59 €

Ni zaloge, predviden rok dobave: 5. 07. 2026.

ÖLFLEX® ROBOT 928 3x0,14

10282517

1.5 kV

142.7 ?/km

0.14 mm2

0,49 €

Ni zaloge, predviden rok dobave: 5. 07. 2026.

ÖLFLEX® ROBOT 928 25x0,14

10282521

1.5 kV

142.7 ?/km

0.14 mm2

3,22 €

Rok dobave sporočimo po obdelavi naročila.

ÖLFLEX® ROBOT 928 4x0,25

10282525

1.5 kV

76.8 ?/km

0.25 mm2

0,86 €

Rok dobave sporočimo po obdelavi naročila.

ÖLFLEX® ROBOT 928 18x0,14

10282520

1.5 kV

142.7 ?/km

0.14 mm2

2,25 €

Ni zaloge, predviden rok dobave: 5. 07. 2026.

ÖLFLEX® ROBOT 928 12x0,25

10282535

1.5 kV

76.8 ?/km

0.25 mm2

2,26 €

Ni zaloge, predviden rok dobave: 5. 07. 2026.

ÖLFLEX® ROBOT 928 25x0,25

10282537

1.5 kV

76.8 ?/km

0.25 mm2

4,72 €

Ni zaloge, predviden rok dobave: 5. 07. 2026.

ÖLFLEX® ROBOT 928 25x0,34

10282545

1.5 kV

57.7 ?/km

0.34 mm2

5,68 €

Rok dobave sporočimo po obdelavi naročila.

ÖLFLEX® ROBOT 928 4x0,14

10282518

1.5 kV

142.7 ?/km

0.14 mm2

0,62 €

Ni zaloge, predviden rok dobave: 5. 07. 2026.

ÖLFLEX® ROBOT 928 7x0,25

10282529

1.5 kV

76.8 ?/km

0.25 mm2

1,47 €

Ni zaloge, predviden rok dobave: 5. 07. 2026.

ÖLFLEX® ROBOT 928 18x0,25

10282536

1.5 kV

76.8 ?/km

0.25 mm2

3,30 €

Rok dobave sporočimo po obdelavi naročila.

ÖLFLEX® ROBOT 928 4x0,34

10282540

1.5 kV

57.7 ?/km

0.34 mm2

1,09 €

Ni zaloge, predviden rok dobave: 5. 07. 2026.

ÖLFLEX® ROBOT 928 12x0,14

10282519

1.5 kV

142.7 ?/km

0.14 mm2

1,55 €

Rok dobave sporočimo po obdelavi naročila.

ÖLFLEX® ROBOT 928 3x0,34

10282539

1.5 kV

57.7 ?/km

0.34 mm2

0,81 €

Rok dobave sporočimo po obdelavi naročila.

ÖLFLEX® ROBOT 928 18x0,34

10282542

1.5 kV

57.7 ?/km

0.34 mm2

4,17 €

Rok dobave sporočimo po obdelavi naročila.

Benefits

Special core stranding allows simultaneous bending and twisting (torsion angle up to ± 180°/m).
UL certification according to technical data enables the product to be used on the North American market.
Product with multiple certifications enables universal use and reduces the variety of parts, thus guaranteeing logistics savings.
With robust, flexible and resistant PVC outer sheath.
Balanced bending and torsional properties for dynamic 3D applications (LAPP performance class "Basic Line").
Proven cable successfully tested for over 2 million bending cycles in cable chains and 2 million torsion cycles.

Applications

The cable design enables flexible, continuously moving use in moving machine parts and cable chains, with horizontal travel distances of up to 5 m.
Suitable for outdoor use, subject to the temperature range.
The PVC outer sheath is resistant to acids and alkalis and has limited oil resistance.
Data cable for applications in automation, production lines and cable chains as well as for robots.
Cable design allows flexible, permanently moving use with torsional stress in robots and handling devices.
Can be used in dry, damp or wet interiors.

Documentation

Notes

If applicable, the prices are solid metal prices without surcharges and VAT. Sales only to business customers.
Unless specified otherwise, the product values shown are rated values at room temperature. You can receive further values, such as tolerances, upon request if they are available and have been released for publication.
Photographs and graphics are not to scale and do not represent detailed images of the respective products.
